PCAP Touch and Pixel Eye

PCAP Displays

Key features

Thinner and lighter touch panel
Multi-touch functionality
Vertically Integrated supply chain
Increase transmission rate and visibility
Improve signal-to-noise ratio (SNR)

KOE developed an LCD module with integrated capacitive multi-touch functionality – Pixel Eyes, and has started to apply in industrial display and equipment. Conventional touch panels formed the transmitter (Tx) and receiver (Rx) layers on an external touch panel module. In Pixel Eyes, the Rx function is incorporated into the shielding layer on the colour filter substrate while the Tx function is incorporated into the common electrode on the TFT substrate. Thus, the touch panel function is integrated in the display. Since it eliminates the need for an external touch panel, thinner and lighter LCD modules are achievable. Furthermore, Pixel Eyes contributes to improvement of visibility by eliminating the discrete touch panel module.

Hectronic offers a wide range of std models with pcap touch and can also make customization from a yearly volume of 300+.

Standard PCAP Touch Series

Product listing

3.5” QVGA - 240 x 320

TX09D200VM0BPA

Technology – TFT
Mode – Transmissive
Dimensions – 68.65 x 88.8 x 10.85
Backlight – 70Khrs LED
Features – Rugged+, IPS, Touchscreen

Data sheet – TX09D200VM0BPA

5.7” VGA - 640 x 480

TX14D23VM5BPA

Technology – TFT
Mode – Transmissive
Dimensions – 131 x 102.2 x 9.1
Backlight – 50Khrs LED
Features – 800 nits, Ultra Wide Viewing Angle, Touchscreen

Data sheet – TX14D23VM5BPA

5.7” VGA - 640 x 480

TX14D28VM5BPA

Technology – TFT
Mode – Transmissive
Dimensions – 131 x 102.2 x 9.1
Backlight – 40Khrs LED
Features – 800 nits, Ultra Wide Viewing Angle, Touchscreen, LVDS

Data sheet –TX14D28VM5BPA

6.5” VGA - 640 x 480

TX17D01VM5BPA

Technology – TFT
Mode – Transmissive
Dimensions – 153 x 118 x 10.2
Backlight – 70Khrs LED
Features – Compact, VGA, LVDS Interface, Touchscreen

Data sheet – TX17D01VM5BPA

6.5” VGA - 640 x 480

TX17D02VM2CPA

Technology – TFT
Mode – Transmissive
Dimensions – 153 x 118 x 10.2
Backlight – 70Khrs LED
Features – Compact, VGA, LVDS Interface, Touchscreen

Data sheet – TX17D02VM2CPA

7.0” FHD - 1920 x 1080

TX18D200VM0EWA

Technology – IPS TFT
Mode – Transmissive
Dimensions – 178.76 x 115 x 11.75
Backlight – 70Khrs LED
Features – IPS, Touchscreen

Data sheet – TX18D200VM0EWA

7.0” WVGA - 800 x 480

TX18D206VM0BPA

Technology – TFT
Mode – Transmissive
Dimensions – 167.7 x 109.5 x 10.6
Backlight – 70Khrs LED
Features – Rugged+, IPS, SHB, LVDS Interface, Touchscreen

Data sheet –TX18D206VM0BPA

7.0” WVGA - 800 x 480

TX18D211VM0BYA

Technology – IPS TFT
Mode – Transmissive
Dimensions – 167.7 x 109.5 x 10.6
Backlight – 50Khrs LED
Features – IPS, Touchscreen, USB I/F

Data sheet – TX18D211VM0BYA

8.0” Compact - 800 x 480

TX20D34VM2BPA

Technology – TFT
Mode – Transmissive
Dimensions – 189 x 120 x 9
Backlight – 50Khrs LED
Features – High Brightness, LVDS, Touchscreen

Data sheet –TX20D34VM2BPA

9.0” WVGA - 800 x 480

TX23D203VM0BPA

Technology – IPS TFT
Mode – Transmissive
Dimensions – 218 x 135 x 12.65
Backlight – 70Khrs LED
Features – Rugged+, IPS, LVDS I/F, Touchscreen

Data sheet – TX23D203VM0BPA

10.4” Compact - 800 x 600

TX26D200VM5BPA

Technology – TFT
Mode – Transmissive
Dimensions – 230 x 180.2 x 12.2
Backlight – 70Khrs LED
Features – Super WVA, Touchscreen

Data sheet –TX26D200VM5BPA

10.1” Wide - 1280 x 800

TX26D207VM0AVA

Technology – IPS TFT
Mode – Transmissive
Dimensions – 265 x 180 x 13.42
Backlight –
Features – Rugged+, IPS, High Brightness, USB-Touch

Data sheet –TX26D207VM0AVA

Innovative PCAP Touch: Thin, Light, and High-Performance Displays

PCAP displays

PCAP Displays

Key features

Product listing

3.5” QVGA - 240 x 320

5.7” VGA - 640 x 480

5.7” VGA - 640 x 480

6.5” VGA - 640 x 480

6.5” VGA - 640 x 480

7.0” FHD - 1920 x 1080

7.0” WVGA - 800 x 480

7.0” WVGA - 800 x 480

8.0” Compact - 800 x 480

9.0” WVGA - 800 x 480

10.4” Compact - 800 x 600

10.1” Wide - 1280 x 800

Learn more about PCAP displays – contact Hectronic.
